Tuttnauer Elara 11 Autoclave and Sterilizer Unit


Tuttnauer Elara 11 Class B Steam Sterilizer

Tuttnauer Elara 11 Class B Automatic Autoclave Sterilizer

The Elara 11 Sterilizer is designed for sterilization of wrapped, porous and hollow loads. The chamber volume is large, external dimensions are small, making it especially suitable for smaller clinics requiring a high turnover. The control system is smart and intuitive, easy to use and has a large memory for consistent and reliable performance.

reg $ 9,299   Discontinued

Tuttnauer Elara 11 sterilizer Brochure


Efficient:

  • Short cycle and high volume pre and post vacuum pump for perfect class B sterilization results
  • 316L grade stainless steel chamber and door with electro-polish finish
  • A built-in steam generator provides steam and facilitates a standby steam mode
  • The door closes smoothly and locks automatically

Features:

  • Large 7.5 Gallon chamber within a small foot print. A perfect fit for standard 24 inch shelves or counters
  • Provided with 5 stainless steel trays and can also hold cassettes
  • Water filling from the front economizes on office space by eliminating the need to keep the top of the autoclave accessible

Tuttnauer Elara 11 Fully Automatic Steam sterilizer


Safety Features:

  • A cycle will not start unless the door is properly locked
  • An automated double locking safety device prevents the door from opening while the chamber is pressurized
  • An automatic safety shut-off prevents overheating of the chamber
  • The autoclave comes with safety pressure-release valves for the chamber and generator

Technical Specifications Elara 11 Autoclave
Chamber Dimensions   11inches (280mm) x 19.8 inches (504mm)
Chamber Volume 7.5gal (28.5L)
Number of Trays 5
Tray Dimensions (WxHxD) 6.7 inches 170mm x 0.8 inches (22mm) x 16.3 inches (442mm)
Voltage(V) Freq.(Hz) 1ph 230 V 50/60 Hz
Current(A) Power(W) 10 A 2300 W
Overall Dimensions (WxHxD) 20.8 inches (530mm) x 17.4 inches (444mm) x 25.4 inches (645mm)
Shipping Weight  184 pounds (84kg) (actual device weight is 148 pounds)
Warranty 1 year, parts and labor

Sterilization Cycles

The Elara 11 Autoclave offers a total of 7 programs: 5 sterilization programs and 2 test programs: Bowie and Dick Test and Vacuum Test. The user can disable programs which allows for savings on validation costs.

Program Instrument and Materials Sterilization Temp Drying Time Average Cycle Time
Flash 273
Unwrapped Instruments 273°F (134°C) 1 Min. 15 Min.
Wdry 273
Wrapped, Porous and Hollow A 273°F (134°C) 20 Min. 42 Min.
NoDry 250
Wrapped Instruments 250°F (121°C) - 35 Min.
WDry 250
Porous Wrapped and Hollow A 250°F (121°C) 20 Min. 60 Min.
Delicate 250
Porous Wrapped and Hollow A 250°F (121°C) - 45 Min.


Door Gasket for Tuttnauer Elara 11 Sterilizer  $ 99.99

 AutoClave Pouch Rack For Elara 11 Sterilizer  $ 80.99

 Chamber Brite Autoclave Cleaner pk 10  $ 41.25
