 Eva Digital X-Ray Sensors -AFP Imaging


Eva Digital X Ray Sensors

Eva Complete Digital X-Ray Sensors By Dent X

EVA Dental Digital X-Ray Sensor is a filmless, digital dental imaging radiology system that produces highest resolution, diagnostic quality images. Utilizing patented “Active Column” CMOS technology, EVA produces high efficiency, low noise images which are digitized and transmitted to your computer via a standard USB (Universal Serial Bus) port and is compatible with laptop or desktop systems. Digital imaging delivers significantly increased revenue to today’s high-tech practice. Requiring less labor, it increases patient throughput and is safer for the patient with reduced X-Ray exposure.

Easy-to-use, state-of-the-art digital imaging eliminates the inconvenience of film processing and the 3 to 6 minute wait for a single X-Ray. Patient archiving is fast and simple for patient data base archives. EVA interfaces with Dent-X ProImage or other image and practice management software suites. The operational simplicity of digital radiography consolidates workflow as it builds productivity.

EVA is suited for multiple uses including endodontic applications and caries detection.

Your EVA System includes...

  • One EVA Sensor Unit - size 1 or 2 (corresponding to standard dental X-Ray film sizes)
  • One Docking Station with USB cable
  • ProImage Dental Image Management Software Suite
  • Starter Kit with Rinn compatible positioning aids and disposable hygienic sheaths
  • Quick Start Guide
  • Installation and Operation User Guide (online)
  • 2 Year warranty

reg $ 8,295   Call for Price

Sensor Size

EVA System Includes:

One EVA Sensor Unit - size 1 or 2 (corresponding to standard dental X-Ray film sizes)EVA Digital Imaging System Specifications EVA System Includes

Installation and Operation User Guide (online)
One Docking Station with USB cable
ProImage Dental Image Management Software Suite

Starter Kit with Rinn compatible positioning aids and disposable hygienic sheaths

Eva digital x-ray systems


Eva digital sensors

Quick Start Guide
EVA Sensor

(Size #2) System Part Number - 9992410200
Active Area: 25.83 mm x 36.03 mm
Capsule Dimensions: 30.82 mm x 44.12 mm x 4.75 mm
Image size (unpacked): 2.1 MB

(Size #1) System Part Number - 9992410100
Active Area: 20 mm x 30 mm
Capsule Dimensions: 25.64 x 38.44 mm x 4.75 mm
Image size (unpacked): 1.3 MB

Sensor Type: Active Column CMOS
Pixel size: 30 μm x 30 μm
Gray Shades: 4096 (12 bits)
Optical Imager Resolution: 16.7 lp/mm
Sensor Cable Length: 2 m (~ 6 ft)

Shipping Weight: 5 lbs (2.27 kg)
EVA Care Warranty: 2 years parts and factory service




  EVA Size #2 EVA+ Size #2 EVA Size #1 EVA+ Size #1
Part number 9992410200 9992411200 9992410100 9992411100
Active area
25.8 mm x 36 mm
20 mm x 30 mm
Capsule dimensions 30.8 mm x 44 mm x 5 mm 32 mm x 47 mm x 6.4 mm 25.6 mm x 38.4 mm x 5 mm 27 mm x 40 mm x 6.4 mm
Image size (unpacked) 2.1 Mb 1.3 Mb
Sensor type
Active Column CMOS
Gray shades
4096 (12 bits)
Optical imager resolution
16.7 lp/mm
Pixel size
30 µm x 30 µm
Sensor cable length
2 m (~6')
Power supply USB powered device - no external power supply needed
Interface EVA USB 1.0 / EVA+ USB 2.0
Shipping weight ~5 lbs.
Warranty 2 Years Parts and Factory Service
Safety certifications FDA, CSA, CE, IEC 60601-1-2
Minimum computer requirements

• Minimum system specifications Win XP for ProImage and EVA to function:
• Operation System - Microsoft Windows XP (Home or Professional) 32-bit with Service Packs installed or Vista 32 Ultimate or Business.
• Processor - Pentium 4 @ 1.5GHz (or equivalent)
• RAM - 1 GB
• USB 2.0 PORT1
• CD Rom Drive
• Hard Drive - 160 GB [based on image storage space for 5,000 images = 10 GB (Estimate)]
• High Quality Display (Flat Panel or CRT)
• LCD Monitor with 800:1 Contrast Ratio and 0.255 dot pitch
• Minimum resolution of 1024x768 @ 32 bits color depth.

Eva Complete Digital X-Ray Sensor System


ProImage Dental Image Management software meets the imaging demands of today's digital practices. It is easy to learn and simple to operate, yet has all the advanced features necessary to deliver rapid, effective diagnoses.

  • Supports digital x-ray, scanned input applications, intraoral cameras, video imaging or any other TWAIN compliant device
  • Multiple language capability
  • No licensing fees - load the software on as many computers as you need
  • Seamless integration with most major practice management software, either directly or with optional ProIntegrate Practice Management Software Bridge


ABELDent Discus
Mediadent
ACE Dental Eaglesoft
meerMANAGER
ADSTRA Easy Dental
MOGO
AltaPoint Exact Dental System
OrthoTrack
Apteryx EZ 2000
Patient Base
AVI Mark First Pacific Power Practice Pro
Computer Age Dentist CADwin Genesis PracticeWorks
Data Team ImageFX Prof. Suni
dental.com Innova SoftDent
DentalEye Integra TDOCS
Dentisoft Intellident TigerView
Dentrix J. Morita Visiodent
DEASCO Lightyear WinOMS

Eva Rinn Positioning System no.870-000284 $ 199

Eva Sensor Sheaths Pk 500 No. 870-000256 $ 90.99

Digital Sensor Sleeves 1.65" x 8" Pk 500  No. 100S $ 19.99

Silver Eva USB Docking Station & Cable No. 9992410040 $ 259

ProImage Imaging Software For Eva Sensors No. 9992490200 $ 599

ProIntegrate Imaging Software Fro Eva Sensors No. 9992410070 $ 799
EVAsoft Imaging Software No. 9992490800 $ 1,399
ProImage To EVAsoft Database Configuration No. 9992810105 $ 799
Eva Additional Sensor Size #1 No. 870-001060 $ Call For Price
Eva Additional Sensor Size #2 No. 9992410800 $ Call For Price
*Eva Guard Enrollment Fee No. 9992410810 $ 249
Eva Guard Annual Fee No. 9992410800 $ 499

* Eva Guard Enrollment Fee waived If EvaGuard Is Purchased With Original Sensor Purchase.

*Eva Guard Deductible $ 2,495


Eva Guard Digital Sensor Warranty

You now have the option to purchase EVA-Guard* - a No-Questions-Asked, robust Equipment Protection program for sensors not covered under warranty.

The Annual Fee for EVA-Guard is $499. There is a one-time Enrollment Fee of $249. Once enrolled in the program, the EVA Replacement Price is significantly reduced.** EVA and EVA-Guard can be purchased from your local dealer.

If you sign up within 30 days of your EVA installation, Dent-X waives the Enrollment Fee.
You can enroll retroactively, but must pay the Enrollment Fee, and all Annual Fees for any uncovered years.

EVA-Guard is renewable each year for 5 years, with the 6th year covered for free. After the termination of the 6th year, the EVA-Guard program concludes for that sensor.

Each EVA sensor is covered under the current and standard factory warranty of 2 years*** with free lifetime remote technical support.

Eva Digital Sensor warranty Form

Click On the Form To Order
